2SWLRQDO)RQW V

406785%2 3ULQ W6\VWHP2SWLRQV

4 Send the emulation to the printer’s hard disk.

If your PC and printer are connected through the parallel port,

type

copy /b *.ps lpt

↵

where

is 1 to 3. (/b refers to binary files.)

 If your PC and printer are connected through the optional

serial port, type

copy /b *.ps com

↵

where

is 1 to 4. (/b refers to binary files.)

 If your PC and printer are connected through the CrownNet

Ethernet port, type

ftp printername↵ (or ftp ipaddress)

bin↵

put filename.ps

quit↵

where printername is the printer’s name, ipaddress is the

printers IP address and filename is the name of the emulation

file.

5 When the downloading is complete, reboot the printer.

The emulation is ready to be used.

2SW LRQD O)RQWV

The following types of optional fonts are available for the QMS 2425/

2425

TURBO

Print System:

 A disk containing typefaces (fonts), such as the ProCollection for

the HP emulations on your printer or other special fonts.

 A SIMM containing 65 ProCollection fonts for the HP emulation

on your printer.
